 H. G. Fischer Archive:  From the Fischer family:
Scale Model Fully-Functioning High Frequency X-Ray Tube

 This tube is an engineering marvel.  Many Thanks to Jonathan, Hannah, Chris, and Warren Fischer for this amazing piece -
It will remain one of our most prized possessions!



This tube is contained in a small Violet Ray type of leatherette case no larger than a 4x6 photograph.



Yet inside is is a tiny X-Ray tube, with a globe scarcely an inch in diameter!

H. G. Fischer & Co. etched on the glass.



Even a small Violet Ray electrode looks large in comparison!


For perspective, here is the full-sized high frequency X-Ray tube!
