The Turn Of The Century Electrotherapy Museum http://www.electrotherapymuseum.com ![]() 13. July 2008 2 Reproductions of Kinraide's Electrical Spark Gap US Patent 623,318 Filed Sept 24, 1898 - Originally shown in US Patent 623,316 Filed May 5, 1898 UK Patent No. 5518, A.D. 1899, Filed 14th Mar 1899; Also Patented in Germany Water-Cooled Quenched Spark Gap ![]() 2 Complete Spark Gaps Click here for a video! ![]() Lever moves bottom plate higher or lower Delta posts allow positioning of plates in the exact same plane ![]() Disassembled ![]() The copper jugs are filled with water to keep the electrode cool. ![]() The sparks form between 2 6" plates. These are aluminum, the originals were copper. ![]() A piece of graphite placed on the gap shows the patterns of spark erosion produced... ![]() Top view. Cork is removable to fill with water! ![]() Bottom view - I used bakelite. ![]() Thomas Burton Kinraide - Originator of the later "Quenched Gap" used in wireless telegraphy (Telefunken gap, later modified by Wein) ![]() Kinraide minding a stopwatch for an X-Ray... ![]() The delicate adjustment of this gap produces unusual discharges. The original tank circuit used only 900V! |
